| Model |
OCL 1325 |
| Working Area |
1300*2500mm |
| Laser Power |
80w/100w/130w/150w |
| Laser Type |
Sealed Co2 Laser Tube,10.6μm |
| Cooling Type |
Water Cooling |
| Engraving Speed |
0-60000mm/min |
| Cutting Speed |
0—40000mm/min |
| Laser Output Control |
0—100% Software Setting |
| Smallest Character Engraving |
2.0*2.0mm1.0*1.0mm / English 1.0mm*1.0mm |
| Highest Scanning Precision |
4000DPI |
| Locating Precision |
≤+0.01mm |
| Controlling Software |
Ruida 6445 Control System |
| Graphic Format Supported |
DST, PLT, BMP, DXF, DWG, AI etc |
| Compatible Software |
TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,All Type of AUTOCAD Sofeware etc |
| Color Separation |
Yes |
| Drive System |
High-precision 3-phase Stepper Motor |
| Auxiliary Equipments |
Exhaust Fan and Air Exhaust Pipe |
| Power Supply |
AC110V/220V+10%,50HZ/60HZ |
| Option |
Up&Down table(Length:500mm),Honeycomb Worktable,Rotary Device Red Dot Position System,Auto-focus Device |
| Application material |
Fabrics, laser, paper, Bamboo ware, acrylic, glass, thin film and canvas |
